DODGE 17Q30R56 WORM GEAR SPEED REDUCER
Quick Overview
Manufactured By: DODGE
Manufacturer Part Number: 17Q30R56
IMS Product Code: 2124027
Packaging: Sold Individually
Description:
Dodge 17Q30R56 Worm Gear Speed Reducer
Right angle worm gear speed reducer with 30:1 ratio, C-face quill input, solid output, 0.875 in output size, and right hand output direction.
Specifications
- Center Distance: 1.7500 in
- Ratio: 30:1
- Horsepower Rating Normal Duty Output: 0.57 hp
- Input Type: C-Face Quill
- Output Type: Solid
- Output Size: 0.8750 in
- Output Direction: Right Hand
- Housing Material: Cast Iron
- Lubrication: PAG, Standard Temperature
- Sealing Type: Single-Lip Contact
- Shaft Diameter Output: 0.875 in
- Shaft Length Output: 1.74 in
- Torque Rating (in-lb) Output: 615 inch pound (pound inch)
- Thermal Horsepower Rating: 1.2 horsepower
- Overhung Load: 1190 lbf
- Case Size: 17
- Product Compatibility: NEMA Motor, 56C Frame
- Type: Standard
- Gear Ratio: 30:1
- Horsepower: 0.76 hp
- Input Size: 5/8 in
- Maximum Speed: 58 rpm
- Torque Rating: 615 in-lb
- Centre Distance: 1-1/2 to 1-3/4 in
- Efficiency: 60 to 95%
- Rotation Type: Right
- Lubrication Type: Synthetic
- Material: Class 30 Gray Iron
- Dimensions: 8.2 in L x 4.89 in W x 7 in H
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 2 hours and 16 minutes.
