DODGE 5B60-SK V-BELT PULLEY
Quick Overview
Manufactured By: DODGE
Manufacturer Part Number: 5B60-SK
IMS Product Code: 2123656
Packaging: Sold Individually
Description:
Dodge 5B60-SK V-Belt Pulley
V-Belt Pulley - A, B Belt Section, 5 Groove, Bushing Required Bore Size, 6.3500 in O.D., QD Bushed, SK Series Bushing, Cast Iron Material
Specifications
- Belt Section Size: A, B
- Number Of Grooves: 5
- Outside Diameter: 6.3500 in
- Bore Type: QD Bushed
- Bushing Series: SK
- Bore Diameter: Bushing Required
- Keyway Size: 1/2 x 1/4 (1-13/16 to 2-1/4 Bore) in, 1/4 x 1/8 (15/16 to 1-1/4 Bore) in, 1/8 x 1/16 (1/2 to 9/16 Bore) in, 3/16 x 3/32 (5/8 to 7/8 Bore) in, 3/8 x 3/16 (1-7/16 to 1-3/4 Bore) in, 5/16 x 5/32 (1-5/16 to 1-3/8 Bore) in, 5/8 x 5/16 (2-5/16 to 2-1/2 Bore) in
- Material: Cast Iron
- Length Through Bore: 1.8750 in
- Face Width: 4.0000 in
- Bushing Bore Range: 7/16 to 2-5/8 in
- Datum Diameter: 5.6000 in
- Pitch Diameter: 5.98 (A) in, 6.36 (B) in
- Pulley Construction: Plain
- Weight: 12.78 lbs
