EATON 10250T1311-53 SELECTOR SWITCH
Quick Overview
Manufactured By: EATON
Manufacturer Part Number: 10250T1311-53
IMS Product Code: 2131246
Packaging: Sold Individually
Description:
Eaton 10250T1311-53 Selector Switch
Selector switch, 30.5 mm, Cam 1, 60° throw, NEMA 3, 3R, 4, 4X, 12, 13, Non-illuminated, 2-position, Knob, Black actuator, 1 NO
Specifications
- Type: Selector Switch
- Size: 30.5mm
- NEMA: 4,4X,13
- Operating Cap: Knob
- Color: Black
- Bezel/Housing: Round Metal, Chrome
- Positions: 2
- Throw: Left-Right, 60-deg
- Contact Mode: Maintained
- Contacts: 1-NO
- Contact Rating: 10A/600V AC
- Cam Code: 1
- Terminals: Standard Screw
- Enclosure Rating: NEMA 3, 3R, 4, 4X, 12, 13, IEC IP65
- Series: 10250T Series
- Diameter: 30.5 mm
- Cam: Cam 1
- Throw: 60°
- NEMA rating: NEMA 3, 3R, 4, 4X, 12, 13
- Illumination: Non-illuminated
- Positions: 2-position
- Actuator: Knob
- Actuator Color: Black
- Contacts: 1 NO
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 21 minutes.
