EBM-PAPST R2E220-AA40-23 CENTRIFUGAL BLOWER
Quick Overview
Manufactured By: EBM-PAPST
Manufacturer Part Number: R2E220-AA40-23
IMS Product Code: 2133290
Packaging: Sold Individually
Description:
ebm-papst R2E220-AA40-23 Centrifugal Blower
Centrifugal blower fan with motorized impeller, 230V AC supply, 530 CFM airflow, ball bearing construction, and flange mount.
Specifications
- Air Flow: 530 CFM
- Bearing Type: Ball Bearing
- Blower Type: Motorized Impeller
- Capacitance: 10 µF
- Current Rating: 430 mA
- Depth: 71 mm
- Diameter: 221.4 mm
- External Depth: 63mm
- Fan Frame Size: 220mm
- Flow Rate - Metric: 14.84m³/min
- Frequency: 60 Hz
- Height: 73 mm
- Housing Material: Polyamide
- Length: 220 mm
- Max Operating Temperature: 40 degrees C
- Mount: Flanges
- Noise Rating: 74dBA
- Operating Supply Voltage: 230 V
- Power Connection Type: 4 Lead Wires
- Power Rating: 100W
- RPM: 2700 RPM
- Supply Voltage: 230VAC
- Termination: Wire Leads
- Voltage Rating: 230 V
- Voltage Type: AC
- Weight: 1.3 kg
- Width: 71 mm
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
