FAFNIR 201K DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: FAFNIR
Manufacturer Part Number: 201K
IMS Product Code: 1909437
Packaging: Sold Individually
Description:
Fafnir 201K Deep Groove Ball Bearing
Single row, deep groove ball bearing with straight bore, 12 mm ID, 32 mm OD, 10 mm width, open type, without snap ring
Specifications
- Bore Type: Straight
- Bore Diameter: 12 mm
- Outside Diameter: 32 mm
- Overall Width: 10 mm
- Closure Type: Open
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: C3
- Max Operating Temperature: 120 degrees C
- Min Operating Temperature: -50 degrees C
- Precision Rating: Not Rated
- Seal Type: Open
- Finish Coating: Uncoated
- Bearing Material: Steel
- Cage Material: Steel
- Max Rpm: 15910 rpm
- Series: 200
- Radial Dynamic Load Capacity: 1730 lbf
- Radial Static Load Capacity: 690 lbf
- Weight: 0.08 lbs
