FAFNIR 2MM215WIDUL ANGULAR CONTACT BALL BEARING
Quick Overview
Manufactured By: FAFNIR
Manufacturer Part Number: 2MM215WIDUL
IMS Product Code: 1924792
Packaging: Sold Individually
Description:
Fafnir 2MM215WIDUL Angular Contact Ball Bearing
Angular Contact Ball Bearing, High Carbon Chrome Steel, 75mm Bore Diameter, 130mm Outside Diameter, 25mm Width, Universal Mounting Arrangement, Open Seal Type, ABEC 7 / P4 Precision Rating
Specifications
- Bore Diameter: 75 mm
- Outside Diameter: 130 mm
- Width: 25 mm
- Material: High Carbon Chrome Steel
- Precision Rating: ABEC 7 / P4
- Seal Type: Open
- Dynamic Load Rating: 80.5 kN / 18100 lbf
- Static Load Rating: 72.5 kN / 16300 lbf
- Limiting Speed: 11000 rpm
- Contact Angle: 15 degrees
- Cage Type: Outer Land Piloted
- Lubricant: Oil/Grease
- Mounting Arrangement: Universal
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
