FAFNIR 9105K DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: FAFNIR
Manufacturer Part Number: 9105K
IMS Product Code: 1924899
Packaging: Sold Individually
Description:
Fafnir 9105K Deep Groove Ball Bearing
Deep groove ball bearing with straight bore, 25 mm ID, 47 mm OD, 12 mm width, open closure, without snap ring
Specifications
- D - Outer Diameter: 47 mm
- Bore Diameter: 25 mm
- Outside Diameter: 47 mm
- Overall Width: 12 mm
- Closure Type: Open
- Seal Type: Open
- Bearing Material: Steel
- Ball Type: STEEL
- Row Type: Single Row Non-Fill Slot
- Radial Dynamic Load Capacity: 2510 lbf
- Radial Static Load Capacity: 1320 lbf
- Limiting Speed (Grease): 8330 rpm
- Limiting Speed (Oil): 9720 rpm
- Max Operating Temperature: 120 degrees C
- Min Operating Temperature: -50 degrees C
- Precision Class: ABEC1
