FAFNIR 9106PP STEEL SINGLE ROW DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: FAFNIR
Manufacturer Part Number: 9106PP
IMS Product Code: 1908697
Packaging: Sold Individually
Description:
Fafnir 9106PP Steel Single Row Deep Groove Ball Bearing
Steel single row deep groove ball bearing with straight bore, double sealed, and without snap ring. Designed for applications with restricted housing diameters and large shaft diameters.
Specifications
- Bore Type: Straight
- Bore Diameter: 30 mm
- Outside Diameter: 55 mm
- Overall Width: 13 mm
- Closure Type: Double Sealed
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: P
- Max Operating Temperature: 120 degrees C
- Precision Rating: Not Rated
- Finish Coating: Uncoated
- Bearing Material: Steel
- Cage Material: Steel
- Max Rpm: 7410 rpm
- Series: 9100
- Radial Dynamic Load Capacity: 3300 lbf
- Radial Static Load Capacity: 1870 lbf
- Weight: 0.26 lbs
- Type Of Bearing: Ball Bearing
- Outer Diameter Type: Cylindrical
- Precision Class: ABEC1
- Relubricatable: No
- Rolling Element: Ball
- Min Operating Temperature: -50 degrees C
- Self Aligning: No
- Retainer Material: Cold Rolled Steel
