FAFNIR PB 1 PILLOW BLOCK BEARING
Quick Overview
Manufactured By: FAFNIR
Manufacturer Part Number: PB 1
IMS Product Code: 2164352
Packaging: Sold Individually
Description:
Fafnir PB 1 Pillow Block Bearing
Pillow block ball bearing unit with 2-bolt base, 1 inch bore, steel construction, and eccentric collar locking device.
Specifications
- Mounting Type: 2-Bolt Base
- Bore Type: Round
- Bore Diameter: 1 in
- Bolt Center To Center Length: 2.8125 to 3.9375 in
- Base To Bore Centerline: 1.1250 in
- Duty Type: Light Duty
- Locking Device: Eccentric Collar
- Seal Type: Contact/Lip
- Housing Material: Steel - Plated
- Expansion Type: Non-Expansion Bearing (Fixed)
- Overall Height: 2.2188 in
- Overall Length: 4.5000 in
- Base Width: 1-1/8 in
- Overall Width: 1.3750 in
- Finish Coating: Uncoated
- Operating Temperature Range: Maximum of +250 degrees F
- Max Rpm: 5440 rpm
- Lubrication Type: Lubrication Fitting
- Series: PB
- Replacement Bearing: RA100RRB
- Weight: 0.65 lbs
- Locking Type: Eccentric Collar
- Number Of Mounting Holes: 2
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships on Monday, September 21, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
