FAG 6200-C-2Z-L038-C3 DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: FAG BEARING
Manufacturer Part Number: 6200-C-2Z-L038-C3
IMS Product Code: 1836571
Packaging: Sold Individually
Description:
Fag 6200-C-2Z-L038-C3 Deep Groove Ball Bearing
Deep groove ball bearing with straight bore, double shielded, single row non-fill slot design. 10mm inner diameter, 30mm outer diameter, 9mm width. C3 internal clearance, steel cage, uncoated finish.
Specifications
- Bore Type: Straight
- Bore Diameter: 10 mm
- Outside Diameter: 30 mm
- Overall Width: 9 mm
- Closure Type: Double Shielded
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: C3
- Operating Temperature Range: -30 to +120 degrees C
- Precision Rating: ABEC 1 (ISO Class Normal)
- Finish Coating: Uncoated
- Cage Material: Steel
- Fillet Radius: 0.6 mm
- Max Rpm: 34500 rpm
- Standards Met: DIN 625-1
- Series: 62
- Radial Dynamic Load Capacity: 6600 N
- Radial Static Load Capacity: 2600 N
- Weight: 0.032 kg
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 11 hours and 23 minutes.
