FESTO 130623 QS-10H-6 PUSH-IN CONNECTOR
Quick Overview
Manufactured By: FESTO
Manufacturer Part Number: 130623
IMS Product Code: 2149865
Packaging: Pack of 10
Description:
Festo 130623 QS-10H-6 Push-In Connector
Festo QS Series Push-In Straight Connector with sleeve for pneumatic connections. 3.8 mm nominal size, 10 mm tube x 6 mm tube, 43.8 mm length. Made of PBT with nickel plating.
Specifications
- Series: QS Series
- Nominal Size: 3.8 mm
- End Style: 10 mm Tube x 6 mm Tube
- Angle: Straight
- Length: 43.8 mm
- Pressure Rating: -0.95 to 14 bar
- Temperature Rating: -10 to 80 deg C
- Material: PBT
- Finish: Nickel Plated
- Pneumatic Connection 1: Push-in sleeve 10 mm
- Pneumatic Connection 2: Push-in connector 6 mm
- Mounting Method: Standard
- Material Tubing Clamp Component: High-alloy stainless steel
- Material Release Ring: POM
- Material Tubing Seal: NBR
- Colour of Release Ring: Blue
- Product Weight: 4.5 g
- Corrosion Resistance Class CRC: 1 - Low corrosion stress
- Operating Medium: Compressed air to ISO 8573-1:2010 [7:-:-]
- Operating Pressure: -0.95 to 6 bar
- Ambient Temperature: -10 to 80 deg C
