FESTO LR-1/8-D-7-MICRO PRESSURE REGULATOR
Quick Overview
Manufactured By: FESTO
Manufacturer Part Number: LR-1/8-D-7-MICRO
IMS Product Code: 2131647
Packaging: Sold Individually
Description:
Festo LR-1/8-D-7-MICRO Pressure Regulator
Festo pressure regulator with 1/8 inch port size and 0.5 to 7 bar pressure range.
Specifications
- Series: LR-D
- Type: Micro
- Port Size: 1/8 in
- Flow Rate: 230 Lpm
- Pressure Range: 0.5 to 7 bar
- Temperature Rating: 14 to 140 deg F
- Material: Wrought Aluminum Alloy
- Weight: 0.127kg
- Pneumatic Connection: 1/8
- Nominal Flow Rate: 450l/min
- Pressure Regulation: 0.5...7bar
- Pressure Gauge: Without
- Ambient Temperature: -10...60 Degrees
- Flow Direction: Left to Right
- Operating Medium: Compressed Air
- Operating Pressure: 1...10bar
- Type of Regulator: Standard
- Design: Directly actuated diaphragm regulator
- Controller function: With secondary venting
- Material sub-base: Wrought aluminium alloy
- Material seals: NBR
- Material housing: Wrought aluminium alloy
- Material membrane: NBR
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
