FESTO MPYE-5-1/8-HF-010-B PROPORTIONAL DIRECTIONAL CONTROL VALVE
Quick Overview
Manufactured By: FESTO
Manufacturer Part Number: MPYE-5-1/8-HF-010B
IMS Product Code: 2122315
Packaging: Sold Individually
Description:
Festo MPYE-5-1/8-HF-010-B Proportional Directional Control Valve
Proportional directional control valve with 5/3-way function, electric actuation, and high-flow capacity.
Specifications
- Nominal size: 6 mm
- Type of actuation: Electric
- Sealing principle: Hard sealing
- Mounting position: Optional
- Valve design: Piston gate valve
- Reset type: Magnetic spring
- Safety position: Closed mid-position
- Piloting type: Direct
- Flow direction: Non-reversible
- Valve function: 5/3 closed
- Operating pressure: 0-10 bar
- Nominal flow rate: 700 L/min
- Limit frequency: 95 Hz
- Hysteresis: 0.4%
- Operational voltage range: 17-30 V DC
- Residual ripple: 5%
- Setpoint/actual value voltage type: 0 - 10 V
- Protection class: IP65
- Product weight: 285 g
- Electrical connection: 4-pin M12x1
- Pneumatic connection: G1/8
- Material cover: ABS/Coated
- Material seals: NBR
- Material housing: Aluminium/Anodised
- Ambient temperature: 0-50 degrees C
- Media temperature: 5-40 degrees C
- Corrosion resistance class: 2 - Moderate
- Conformity: RoHS-compliant, VDMA24364-B2-L, RCM, KC-EMV, CE mark
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 6 hours and 35 minutes.
