FESTO VMPA2-M1BH-E-PI SOLENOID VALVE
Quick Overview
Manufactured By: FESTO
Manufacturer Part Number: VMPA2-M1BH-E-PI
IMS Product Code: 2127477
Packaging: Sold Individually
Description:
Festo VMPA2-M1BH-E-PI Solenoid Valve
20mm wide solenoid valve with 5/3-way valve function.
Specifications
- Series: VMPA
- Nominal Size: 20 mm
- Pressure Rating: -0.9 to 10 bar
- Temperature Rating: -5 to 50 degrees C
- Flow Rate: 750 Lpm
- Number of Ways: 5
- Number of Positions: 3
- Media: Compressed Air
- Actuator Type: Electrical
- Body Material: Die-Cast Aluminum
- Softgoods Material: NBR
- Dimensions: 112.9 mm L x 28.8 mm W x 52.2 mm H
- Valve Function: 5/3 exhausted
- Actuation Type: Electric
- Reset Type: Mechanical spring
- Protection Degree: IP65
- Sealing Principle: Soft sealing
- Piloting Type: Pilot actuated
- Flow Direction: Reversible
- Signal Status Display: Yes
- Suitability for Vacuum: Yes
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
