FESTO ZSB-1/8-B CONTROL BLOCK
Quick Overview
Manufactured By: FESTO
Manufacturer Part Number: ZSB-1/8-B
IMS Product Code: 2153241
Packaging: Sold Individually
Description:
Festo ZSB-1/8-B Control Block
Pneumatic control block for two-hand start safety function, Category 1 Performance Level c, 4mm nominal size, G1/8 pneumatic connection
Specifications
- Nominal Size: 4mm
- Type of Actuation: Pneumatic
- Mounting Position: Optional
- Safety Function: Two-hand control
- Performance Level: Category 1, Performance Level c (PL)
- Operating Pressure: 0.4MPA, 0.8MPA, 4BAR, 8BAR
- Operating Medium: Compressed air to ISO 8573-1:2010 [7:4:4]
- Lubricated Operation: Possible
- Shock Resistance: Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27
- Corrosion Resistance Class: 1 - Low corrosion stress
- Product Weight: 420G
- Type of Mounting: Either: With through-hole or Via female thread
- Material Cover: Die-cast aluminium
- Material Seals: NBR
- Material Housing: Wrought aluminium alloy, Anodised
- Ambient Temperature: 0GC to 60GC
- Pneumatic Connection: G1/8 , port 2 and 3
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 48 minutes.
