GE FANUC IC693MDL740F DC OUTPUT MODULE
Quick Overview
Manufactured By: GE FANUC
Manufacturer Part Number: IC693MDL740F
IMS Product Code: 2153496
Packaging: Sold Individually
Description:
GE Fanuc IC693MDL740F DC Output Module
12/24 VDC positive logic output module with 16 points, 0.5 A per point.
Specifications
- Rated Voltage: 12/24 volts DC
- Number of Outputs: 16
- Output Current: 0.5 A per point
- Output Voltage Range: 12 to 24 volts DC (+20%, -15%)
- DC Power: Yes
- Type: PLC Output Module
- Series: VersaMax, 90-30
- Weight: 0.3 kg, 345 gm
- Nominal Voltage Output: 12/24 V DC
- Inrush Current: 4.78 A for 10 ms
- Current Capacity: 0.5 A per channel
- Output Current Per Common: 2 A for 10 ms
- Groups: 2
- Channels per Group: 8
- Temperature Range: -20 degrees C to 60 degrees C
- Operating Humidity: 5% to 95% RH
- Isolation Voltage: 1500 V AC for 1 min
- Response Time: 5 ms typical
- Mounting Type: DIN rail or panel mount
- Logic: Positive logic (sinks current to turn on)
- Form factor: Single slot module
Used (Special):
Missing terminal cover
