GENERAC XVT076A03 PWRCELL INVERTER
Quick Overview
Manufactured By: GENERAC
Manufacturer Part Number: XVT076A03
IMS Product Code: 2175401
Packaging: Sold Individually
Description:
Generac XVT076A03 PWRcell Inverter
7.6kW single-phase grid-tie/ hybrid inverter with smart battery integration
Specifications
- Power Rating: 7.6kW
- Phase: 1Ph
- Inverter Type: PWRcell
- AC Output Voltage: 120/240 VAC
- Maximum Continuous Output Current: 32 A, RMS
- DC Input Voltage Range: 360-420 VDC
- Nominal DC Bus Voltage: 380 VDC
- Max Input Current: 20 A
- Peak Efficiency: 97%
- CEC Weighted Efficiency: 96.5%
- Dimensions (W x H x D): 24.5" x 19.25" x 8"
- Weight: 62.7 lbs
- Certifications: ETL, cETL, UL 1741 SA, CSA 22.2, UL 1998
