GENERAL BEARING 77R6 RADIAL BALL BEARING
Quick Overview
Manufactured By: GENERAL BEARING
Manufacturer Part Number: 77R6
IMS Product Code: 1896417
Packaging: Sold Individually
Description:
General Bearing 77R6 Radial Ball Bearing
Single Row Radial Bearing 3/8" ID x 7/8" OD x 9/32" Wide Double Shielded No Snap Ring Standard (ABEC 1)
Specifications
- Bore Type: Straight
- Bore Diameter: 0.3750 in
- Outside Diameter: 0.8750 in
- Overall Width: 0.2813 in
- Closure Type: Double Shielded
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: C3
- Finish Coating: Uncoated
- Cage Material: Steel
- Max Rpm: 36000 rpm
- Series: R
- Radial Dynamic Load Capacity: 750 lbf
- Radial Static Load Capacity: 317 lbf
- Ball Material: Steel
- Fillet Radius: 0.016 in
- Precision: Standard
- Capacity: Standard Capacity
- Locking Device: No Locking Device
- Lubricant: General Purpose
- Bearing Type: Radial
- Contact Angle: 0 degrees
- Material: Steel
- Cage Type: Metal
- Temperature Range [Max]: 350 degrees F
- Temperature Range [Min]: -20 degrees F
- Seal Material: Metal
- Enclosure: Double Shielded
- Preload Level: None
- Rows of Balls: Single
- Precision Level: Standard (ABEC 1)
- Weight: 0.029 LB
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 8 hours and 56 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 8 hours and 56 minutes.
