HONEYWELL V5862A2054 1/2" NPT BRASS GLOBE VALVE
Quick Overview
Manufactured By: HONEYWELL
Manufacturer Part Number: V5862A2054
IMS Product Code: 1877400
Packaging: Sold Individually
Description:
Honeywell V5862A2054 1/2" NPT Brass Globe Valve
Two-way cartridge globe valve with 1/2" NPT connection, brass body, stainless steel stem, 1.9 Cv flow capacity
Specifications
- Connection: NPT
- Cv: 1.9
- Pattern: 2-way
- Size: 1/2 in
- Body Material: Brass
- Stem Material: Stainless Steel
- Seat Material: Brass
- Cartridge Material: Brass
- Flow Characteristic: Equal Percentage
- Pressure Rating: 230 psig
- Media Temperature Range: 36 to 230 degrees F
- Stroke: 1/4"
- Max Close-Off Pressure: 174 psi
- Max Static Pressure: 235 psi
- Leakage Rating: ANSI Class IV
- Dimensions: 74 mm high x 19 mm wide x 76 mm deep
