More Views
IFM EVC100 M12 CORDSET CABLE
Quick Overview
Manufactured By: IFM
Manufacturer Part Number: EVC100
IMS Product Code: 2146022
Packaging: Sold Individually
Description:
Ifm EVC100 M12 Cordset Cable
M12 male to female, 3m PUR cable, 4-pin, 4A, 250V AC/300V DC
Specifications
- Cable Length: 3 m
- Wire Size: 0.34 sq mm
- End 1 Number of Pins: 4
- End 2 Number of Pins: 4
- IP Rating: IP65, IP67, IP68, IP69K
- End 1 Connection Type: M12
- End 2 Connection Type: M12
- Max. Amps: 4 A
- Max. Voltage: 250 V AC, 300 V DC
- End 1 Gender: Male
- End 2 Gender: Female
- End 1 Mounting Orientation: Straight
- End 2 Mounting Orientation: Straight
- Cable Jacket Color: Black
- Cable Jacket Material: PUR
- Maximum Operating Temperature: 194 Degrees F
- Minimum Operating Temperature: -13 Degrees F
- Special Feature: Free From Silicone; Halogen-Free; Gold-Plated Contacts; Drag Chain Suitability
- Operating Voltage [V]: < 250 AC / < 300 DC
- Protection Class: II
- Protection: IP 65; IP 67; IP 68; IP 69K
Request A Quote
Let us know your requirements and an IMS Supply representative will provide you with a detailed quote.
Shipping Times Provided In Quote
