KHK NSU1-30 NYLON SPUR GEAR WITH STEEL CORE
Quick Overview
Manufactured By: KHK GEARS
Manufacturer Part Number: NSU1-30
IMS Product Code: 2138340
Packaging: Sold Individually
Description:
KHK NSU1-30 Nylon Spur Gear with Steel Core
Nylon spur gear with steel core, module 1, 30 teeth.
Specifications
- Module: 1
- No. of teeth: 30
- Bore Type: Plain
- Bore (A): 8.0 mm
- Hub Diameter (B): 20.0 mm
- Pitch Diameter (C): 30.00 mm
- Outer Diameter (D): 32.00 mm
- Face Width (E): 10.0 mm
- Hub Width (F): 10.0 mm
- Total Length (G): 20.00 mm
- Metal Core Diameter (H): 20.0 mm
- Material: MC602ST Reinforced Nylon with S45C Carbon Steel core
- Pressure Angle: 20 degrees
- Precision Grade: JIS grade N9
- Weight: 0.04600 kg
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 12 hours and 52 minutes.
