KHK GEARS SSA4-35 MODULE 4, 35 TOOTH, CARBON STEEL HUBLESS GEAR
Starting At: $109.25
Quick Overview
Manufactured By: KHK GEARS
Manufacturer Part Number: SSA4-35
IMS Product Code: 1790431
Packaging: Sold Individually
Description:
Khk SSA4-35 Module 4, 35 Tooth, Carbon Steel Hubless Gear
Specifications:
- Gear Type: Spur Gears
- Construction: Carbon Steel Hubless Gears
- Bore Type: Plain
- Module: 4
- No. of teeth: 35
- Shape: S5
- Bore (A): 25.0 (mm)
- Pitch Diameter (C): 140.0 (mm)
- Outer Diameter (D): 148.0 (mm)
- Face Width (E): 40.0 (mm)
- Total Length (G): 40.00 (mm)
- Bending Strength (N-m): 795.0000
- Surface Durability (N-m): 81.6000
- Bending Strength (kgf-m): 81.1000
- Surface Durability (kgf-m): 8.32
- Backlash: 0.20-0.44 (mm)
- Weight: 4.68 (kg)
- Precision Grade: JIS grade N8 (JIS B1702-1:1998) JIS grade 4 (JIS B1702:1976)
- Gear Teeth Type: Standard full depth
- Pressure Angle: 20°
- Material: S45C (AISI 1045) Carbon Steel
- Tooth Hardness: (less than 194HB)
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships on Monday, May 20, 2024
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 3 In Stock
Ships on Monday, May 20, 2024
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
