KHK SUSA2-42 STAINLESS SPUR GEAR
Quick Overview
Manufactured By: KHK GEARS
Manufacturer Part Number: SUSA2-42
IMS Product Code: 2089581
Packaging: Sold Individually
Description:
KHK SUSA2-42 Stainless Spur Gear
Stainless steel spur gear with 42 teeth, module 2, 15 mm bore diameter, and 20 degrees pressure angle.
Specifications
- Material: Stainless Steel
- Material Grade: SUS303
- Number of Teeth: 42
- Metric Module Pitch: 2
- Bore Diameter: 15 mm
- Bore Type: Plain
- Bore Diameter Tolerance: H7
- Hub Type: No Hub
- Gear Shape: S5
- Face Width: 20 mm
- Pitch Diameter: 84 mm
- Outside Diameter: 88 mm
- Pressure Angle: 20 Degrees
- Maximum Teeth Hardness: 187 HB
- Precision Class: JIS N8 (JIS B1702-1:1998)
- System of Measurement: Metric
- Resistance Properties: Rust Resistant
- Standards: RoHS Compliant
- Weight: 0.837
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 13 hours and 49 minutes.
