KOYO 32216JR TAPERED ROLLER BEARING
Quick Overview
Manufactured By: KOYO
Manufacturer Part Number: 32216JR
IMS Product Code: 1915239
Packaging: Sold Individually
Description:
Koyo 32216JR Tapered Roller Bearing
Tapered roller bearing with 80 mm inner diameter, 140 mm outer diameter, and 35.25 mm width.
Specifications
- d: 80 mm
- D: 140 mm
- T: 35.25 mm
- B: 33 mm
- C: 28 mm
- r(min.): 2.5 mm
- r1(min.): 2 mm
- Basic load ratings : Cr: 253 kN
- Basic load ratings : C0r: 271 kN
- Fatigue load limit : Cu: 41.5 kN
- Limiting speeds(Grease lub.): 2700 min-1
- Limiting speeds(Oil lub.): 3600 min-1
- Load center spread : a: 31.7 mm
- Constant e: 0.42
- Axial load factors : Y1: 1.43
- Axial load factors : Y0: 0.79
- da(min.): 92 mm
- db(max.): 90 mm
- Da(max.): 130 mm
- Da(min.): 122 mm
- Db(min.): 134 mm
- Sa(min.): 4 mm
- Sb(min.): 7 mm
- ra(max.): 2 mm
- rb(max.): 2 mm
- Mass: 2.17 kg
- Cage Material: Pressed Steel
- Number of Rows: 1
- Series: Metric Series
- Type: Caged
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
