LEGRAND 1024351 AUTOMATIC SWITCH
Quick Overview
Manufactured By: LEGRAND
Manufacturer Part Number: 1024351
IMS Product Code: 2143431
Packaging: Sold Individually
Description:
Legrand 1024351 Automatic Switch
3-pole automatic switch, 1000A, 33.5kA, stationary installation, IP20 protection.
Specifications
- Current Type: AC
- Installation: Stationary
- Voltage: 660 V
- Drive Type: Manual
- Product Type: Molded Case Circuit Breaker
- Mounting Method: Mounting Plate
- Protection Degree: IP20
- Nominal Current: 1000 A
- Trip Unit Type: Without Trip Unit
- Number of Poles: 3
- Device Construction: Fixed Installation (Stationary)
- Climate Version: UHL3
- Design Execution: Complete Device in Housing
- Number of Power Poles: 3
- Built-in Motor Drive: No
- Optional Motor Drive: No
- Nominal Continuous Current Iu: 1000 A
- Additional Trip Unit Type: None
- Circuit Breaker Scheme: 300016
- Nominal Breaking Capacity: 33.5 kA
- Main Electrical Circuit Connection: Front Connection
- Undervoltage Trip: No
- Nominal Breaking Capacity Icu at 400 V, 50 Hz: 33.5 kA
- Magnetic Trip Setting Im: 16In A
- Overload Protection Adjustment Range: 300...1100 A
- Short Circuit Trip Short Delay Range: 450 ... 13200 A
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships on Monday, October 13, 2025
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
