MARTIN 50BS21 1 7/16 SPROCKET
Quick Overview
Manufactured By: MARTIN
Manufacturer Part Number: 50BS21 1 7/16
IMS Product Code: 1843182
Packaging: Sold Individually
Description:
Martin 50BS21 1 7/16 Sprocket
Steel sprocket with 21 teeth, 5/8 inch pitch, 1.4375 inch bore diameter
Specifications
- Bore Diameter: 1.4375 in
- Bore Type: Bored to Size
- Caliper Diameter: 3.7817 in
- Chain Number & Pitch: 50 / 5/8 in
- Chain / Sprocket Type: Standard Roller Chain
- Hardened Teeth: Non-Hardened Teeth
- Hub Diameter: 3 in
- Keyway Size: 3/8 x 3/16 in
- Length Through Bore: 1.0000 in
- Material: Steel
- Number Of Hubs: 1
- Number Of Strands Across: 1
- Number Of Teeth: 21
- Outside Diameter: 4.5220 in
- Pitch Diameter: 4.1934 in
- Pitch Type: Single
- Product Type: Finished & Machinable Bore Roller Chain Sprockets
- Storage Dimension Height: 1.0625 in
- Storage Dimension Length: 4.6250 in
- Storage Dimension Width: 4.6250 in
- Surface Treatment: Protective Coating
- Tooth Width: 0.343 in
- Weight: 1.98 lbs
