MARTIN 60BS10HT-1-3/16 SPROCKET
Quick Overview
Manufactured By: MARTIN
Manufacturer Part Number: 60BS10HT-1-3/16
IMS Product Code: 2128595
Packaging: Sold Individually
Description:
Martin 60BS10HT-1-3/16 Sprocket
Steel roller chain sprocket with hardened teeth, B-hub one side, finished bore, and keyway.
Specifications
- Chain Size: 60
- Number of Teeth: 10
- Number of Rows of Teeth: 1
- Hub Type: B-Hub One Side
- Mounting Method: Finished Bore
- Bushing Size if bushed: No Bushing
- Hardened Teeth: Yes
- Chain Type: ANSI Roller Chain
- Keyway Yes/No: Yes
- Material: Steel
- Outside Diameter: 2.759 Inch | 70.079 Millimeter
- Bore: 1.188 Inch | 30.175 Millimeter
- Pitch Diameter: 2.427 Inch | 61.64 Millimeter
- Chain Pitch: 0.75 Inch | 19.05 Millimeter
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships on Monday, September 22, 2025
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
