MOELLER PKZM4-40 MOTOR PROTECTOR
Quick Overview
Manufactured By: MOELLER ELECTRIC
Manufacturer Part Number: PKZM4-40
IMS Product Code: 1904033
Packaging: Sold Individually
Description:
Moeller PKZM4-40 Motor Protector
3-phase thermal-magnetic motor protective device with adjustable bimetal trips for motor overload protection and magnetic trips for short circuit protection.
Specifications
- Adjustable Amp Range: 32 - 40
- Breaking Capacity: 50kA @ 400V AC
- Class: 10
- Connection Type: Screw Terminal
- Degree of Protection: IP20
- Frame Size: D
- Lifespan, Electrical: 100,000 operations
- Lifespan, Mechanical: 100,000 operations
- Maximum Backup Circuit Breaker (CL): 600A
- Maximum Backup Fuse (CL): 600A
- Mounting Type: DIN rail or screw mounting
- Number of Poles: 3
- Operating Temperature: -25 degrees C to +55 degrees C
- Overload Release Range: 32-40A
- Rated Frequency: 40-60Hz
- Rated Impulse Withstand Voltage: 690v
- Rated Operating Voltage: 600V
- Short Circuit Release: 448A
- Short Circuit Release Tolerance: +/- 20%
- Short-Circuit Breaking Capacity: 50kA @ 600V
- Trip Type: Thermal-Magnetic
- Voltage Rating: 690V AC
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
