More Views
MRC 5206CFF ANGULAR CONTACT BEARING
Quick Overview
Manufactured By: MRC
Manufacturer Part Number: 5206CFF
IMS Product Code: 1923767
Packaging: Sold Individually
Description:
MRC 5206CFF Angular Contact Bearing
Double Row Angular Contact Bearing - 30 mm Bore, 62 mm OD, 0.9375 in Width, Open, Without Snap Ring, 30 degrees Contact Angle, C3
Specifications
- Bore Type: Straight
- Bore Diameter: 30 mm
- Outside Diameter: 62 mm
- Overall Width: 0.9375 in
- Row Type: Double-Row Non-Fill Slot
- Closure Type: Open
- Snap Ring Included: Without Snap Ring
- Duplex Type: Single
- Bearing Type: Angular Contact Bearings
- Contact Angle: 30 degrees
- Bearing Material: Chrome Steel
- Internal Clearance: C3
- Radial Dynamic Load Capacity: 6430 lbf
- Radial Static Load Capacity: 4590 lbf
- Cage Material: Steel
- Inner Ring Width: 23.813 mm
- Element Material: Bearing steel
- Max Rpm: 9500 rpm
- Finish Coating: Uncoated
- Precision Rating: Not Rated
- Fillet Radius: 1 mm
- Series: 5200-C
- Weight: 0.69 lbs
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 7 hours and 2 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 7 hours and 2 minutes.
