MURR ELEKTRONIK 57327 DIGITAL OUTPUT MODULE
Quick Overview
Manufactured By: MURR ELEKTRONIK
Manufacturer Part Number: 57327
IMS Product Code: 1896404
Packaging: Sold Individually
Description:
Murr Elektronik 57327 Digital Output Module
Compact module for digital output, part of the Cube20S series. Features relay outputs with 3A capacity at 230V AC.
Specifications
- Dimensions H x W x D: 109x12.9x76.5 mm
- Current consumption: max. 130 mA
- Protection: IP20
- Connection: Spring clamp plug-in terminals: max. 1.5 mm^2 (AWG 16)
- Mounting method: DIN-rail mountable (EN 60715)
- Temperature range: 0 - 60 degrees Celcius (storage temperature -25 - 70 degrees Celcius)
- Actuator supply UA: max. 30 V DC/230 V AC
- Switching current per output: max. 3 A (short-circuit and overload protected)
- Galvanic isolation: 500 V DC between outputs and internal communication
- Weight: 65 g
- Series: Field Bus System
