NEXEN 910200 TOOTH CLUTCH
Quick Overview
Manufactured By: NEXEN GROUP
Manufacturer Part Number: 910200
IMS Product Code: 2128092
Packaging: Sold Individually
Description:
Nexen 910200 Tooth Clutch
Air Engaged, Spring Released, Pilot Mount, Non-Positioning Tooth Clutch with 1.5 inch bore and machined aluminum air chamber.
Specifications
- Clutch Type: Tooth Clutch
- Mounting Configuration: Shaft Mounted
- Engagement/Release: Air Engaged/Spring Release
- Design: Open
- Bore Type: Finished w/ Keyway & 2 SS
- Drive Arrangement: Pilot Mount
- Port Size: 1/8 NPT
- Max Rpm: 3000 rpm
- Min Static Torque Capacity: 1230 inlb
- Bore Diameter: 1.5 in
- Max Pressure: 80 psi
- Min Engagement Pressure: 20 psi
- Air Chamber Volume: 0.763 in³
- Ratings: CE and RoHS
- Weight: 17 lbs
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 13 hours and 35 minutes.
New - Missing Box (Special):
Comes with hose.
Availability: 1 In Stock
Ships today if ordered in the next 12 hours and 35 minutes.
