NISSEI H2LM-28L-30-T040A INDUCTION GEAR MOTOR
Quick Overview
Manufactured By: NISSEI CORP.
Manufacturer Part Number: H2LM-28L-30-T040A
IMS Product Code: 2145197
Packaging: Sold Individually
Description:
Nissei H2LM-28L-30-T040A Induction Gear Motor
Induction gear motor with 0.4kW capacity, three-phase, IP44 protection.
Specifications
- Output Axis Rotation Speed: 50r/min / 50Hz, 60r/min / 60Hz
- Output Axis Allowable Torque: 69 N?m / 50Hz, 57 N?m / 60Hz
- Output Axis Allowable O.H.L: 2210N
- Allowable Inertia Moment: 0.0015kg·?
- Reduction Gear Specifications Output Axis Type: ???/???
- Case Material: ???
- Frame Number and Output Axis Diameter: 28 mm
- Reduction Ratio: 1/30
- Output Axis Material: ???
- Motor Type: ?????
- Motor Capacity: 0.4kW(1/2HP)
- Phase Number: ??
- Voltage Frequency Rated Current Rated Rotation Speed: 200V / 50Hz / 2.1A / 1410r/min, 200V / 60Hz / 1.8A / 1690r/min, 220V / 60Hz / 1.8A / 1710r/min
- Protection Structure: IP44
- Time Rating: S1 CONT.
- Terminal Box: A?
- Mass: 11 kg
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 6 hours and 26 minutes.
