NSD MRE-G160SP062FBC MULTI-TURN ABSOCODER
Quick Overview
Manufactured By: NSD CORPORATION
Manufacturer Part Number: MRE-G160SP062FBC
IMS Product Code: 2150016
Packaging: Sold Individually
Description:
NSD MRE-G160SP062FBC Multi-turn Absocoder
Multi-turn type ABSOCODER sensor with 10mm shaft and 9-pin F mount. Cylinder type with servo-mount/flange-mount design and flat/key way shaft. Total number of turns: 160, divisions per turn: 4096.
Specifications
- Shape: Cylinder type
- Type: Standard
- Mounting: Servo-mount type/Flange-mount type
- Shaft shape: Flat/Key way
- Connector type: Cable & connector
- Total number of turns: 160
- Divisions/Turn: 4096
- Total number of divisions: 131072
- Mass: 1.0 kg
- Linearity error: 2 Max.
- Moment of inertia: 3.9×10-6 kg·m2
- Starting torque: 4.9×10-2 N·m or less
- Permissible shaft load Radial: 98 N
- Thrust: 49 N
- Permissible mechanical speed: 3600 r/min
- Bearing life: 1.5×104 h
- Ambient temperature Operating: -20 to +60°C
- Storage: -30 to +90°C
- Vibration resistance: 2.0×102 m/s2
- Shock resistance: 4.9×103 m/s2
- Protection rating: IP52f
- Max. sensor cable length Standard cable: 100 m
- Robotic cable: 40 m/70 m
- Interconnecting sensor cable: 2 m
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 38 minutes.
