NSK 22211EAKE4C3 SPHERICAL ROLLER BEARING
Quick Overview
Manufactured By: NSK
Manufacturer Part Number: 22211EAKE4C3
IMS Product Code: 2149553
Packaging: Sold Individually
Description:
NSK 22211EAKE4C3 Spherical Roller Bearing
Spherical roller bearing with a high capacity steel cage, an annular groove in the outer ring with three lubrication holes, and a greater than standard radial internal clearance.
Specifications
- Bore Type: Tapered 1:12
- Outer Ring Type: Not Split
- Bore Diameter: 55 mm
- Outside Diameter: 100 mm
- Overall Width: 25 mm
- Cage Type: Inner Ring Guided
- Closure Type: Open
- Internal Clearance: C3
- Lubrication Hole Type: Lubrication Groove & Hole
- Measurement Standard: Metric
- Max Rpm: 6700 rpm
- Operating Temperature Range: Maximum of +200 degrees C
- Cage Material: Steel Cage
- Bearing Material: Steel
- Precision Rating: RBEC 1 (ISO Class Normal)
- Finish Coating: Uncoated
- Outer Ring Width: 25 mm
- Fillet Radius: 1.50 mm
- Series: 222
- Weight: 1.76 lbs
- Dynamic Load Rating (kN): 119
- Grease Limiting Speed (r/min): 4500
- Static Load Rating (kN): 144
- Oil Limiting Speed (r/min): 5600
