NTN 3780 TAPERED ROLLER BEARING CONE
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 3780
IMS Product Code: 1838634
Packaging: Sold Individually
Description:
NTN 3780 Tapered Roller Bearing Cone
Tapered roller bearing cone with 2 in bore diameter, 1.193 in width, and case carburized steel material.
Specifications
- Bore Type: Round
- Bore Diameter: 2 in
- Overall Width: 1.193 in
- Bearing Material: Case Carburized Steel
- Fillet Radius: 0.1400 in, 3.600 mm
- Inner Ring Width: 1.193 in
- Operating Temperature Range: -40 to 250 degrees F
- Finish Coating: Uncoated
- Weight: 1.208 lbs
- Outside Diameter: 3.461 in
- Cone Width: 1.192 in
- Ring Material: Alloy Steel
- Ring Material Grade: 52100
- Cage Material: Pressed Steel
- Roller Material: Alloy Steel
- Roller Material Grade: 52100
- Number of Rows: One
- Dynamic Radial Load Capacity: 113 kN
- Static Radial Load Capacity: 134 kN
- Shaft Fillet Radius: 0.137 in
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 15 hours and 19 minutes.
