NTN 51105 THRUST BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 51105
IMS Product Code: 2145215
Packaging: Sold Individually
Description:
NTN 51105 Thrust Ball Bearing
Single Direction Thrust Ball Bearing, separable, round bore, molded resin cage, high carbon chrome steel construction
Specifications
- Type: Thrust Ball Bearing
- Bore Type: Round
- Outside Ring Type: Straight
- Material: High Carbon Chrome Steel
- Cage Type: Molded
- Cage Material: Resin
- Ball Material: Steel
- Limiting Speed - Oil: 6500 RPM
- Limiting Speed - Grease: 4600 RPM
- Precision: ISO Class 0
- Configuration: One
- Radial Internal Clearance: CN
- Static Load Rating: 8300 lbf, 37000 N, 37.00 kN
- Dynamic Load Rating: 4400 lbf, 19600 N, 19.60 kN
- Enclosure: Open
- Weight: 0.115 lb, 0.052 kg
- Operating Temperature Range: -40 to 250 degrees F, -40 to 120 degrees C
- d: 0.9843 in, 25.000 mm
- D1: 1.0236 in, 26.000 mm
- d1: 1.6535 in, 42.000 mm
- D: 1.6535 in, 42.000 mm
- T: 0.4331 in, 11.000 mm
- r: 0.0236 in, 0.600 mm
- da min: 1.3780 in, 35.000 mm
- Da max: 1.3780 in, 35.000 mm
- ras max: 0.0236 in, 0.600 mm
- Series: 511
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
