NTN 6207ZZ DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: 6207ZZ
IMS Product Code: 2167141
Packaging: Sold Individually
Description:
NTN 6207ZZ Deep Groove Ball Bearing
Deep groove ball bearing with straight bore, double shielded, and without snap ring. Dimensions: 35 mm ID, 72 mm OD, 17 mm width.
Specifications
- Bore Type: Straight
- Bore Diameter: 35 mm
- Outside Diameter: 72 mm
- Overall Width: 17 mm
- Closure Type: Double Shielded
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: CN/C0
- Operating Temperature Range: -40 to 250 degrees F
- Cage Type: Pressed
- Precision Rating: ISO Class 0
- Bearing Material: High Carbon Chrome Steel
- Cage Material: Steel
- Fillet Radius: 1.100 mm
- Max Rpm: 11000 rpm
- Series: 62
- Radial Dynamic Load Capacity: 6380 lbf
- Radial Static Load Capacity: 3450 lbf
- Weight: 0.626 lbs
