NTN NATR40 NEEDLE ROLLER BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: NATR40
IMS Product Code: 2121255
Packaging: Sold Individually
Description:
NTN NATR40 Needle Roller Bearing
Yoke type track roller bearing with inner ring, needle roller bearing, high carbon chrome steel material, open enclosure, spherical outside diameter.
Specifications
- Type: Yoke Type Track Roller
- Roller Type: Needle
- Bearing Type: Needle Roller Bearing
- Material: High Carbon Chrome Steel
- Cage Material: Steel
- Outside Ring Type: Spherical
- Limiting Speed - Oil: 4000 RPM
- Limiting Speed - Grease: 3000 RPM
- Enclosure: Open
- Static Load Rating: 20795 lbf, 92500 N, 92.50 kN
- Dynamic Load Rating: 11128 lbf, 49500 N, 49.50 kN
- Load Rating of Track: 2200 lbf, 9800 N
- Weight: 1.929 lb, 0.870 kg
- Operating Temperature Range: -40 to 250 degrees F, -40 to 120 degrees C
- d: 1.5750 in, 40.000 mm
- D: 3.1496 in, 80.000 mm
- F: 1.9685 in, 50.000 mm
- e: 2.5984 in, 66.000 mm
- C: 1.1811 in, 30.000 mm
- B: 1.2598 in, 32.000 mm
- B Tolerance: 0/-0.250 mm
- Roller Shape: Crowned
- Roller Diameter: 80 mm
- Bore Diameter: 40 mm
- Roller Width: 30 mm
- Bearing Element: Needle Rollers
- Overall Width: 32 mm
- Closure Type: Open
- Radial Dynamic Load Capacity: 11100 lbf
- Radial Static Load Capacity: 20800 lbf
- Max Rpm: 4000 RPM
- Series: NATR
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
