NTN UC210-200D1 INSERT BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: UC210-200D1
IMS Product Code: 2155853
Packaging: Sold Individually
Description:
NTN UC210-200D1 Insert Bearing
Ball Insert Bearing - Cylindrical Bore, 2 in Bore Diam., 3.5433 in OD, 2.0315 in Width, Standard Duty, Set Screw Locking
Specifications
- Type: Insert Bearing
- Bore Type: Round
- Bearing Type: Ball Bearing
- Material: Through Hardened Steel
- Ball Material: Steel
- Limiting Speed - Grease: 3100 RPM
- Seal Type: Contact
- Seal Material: Nitrile Rubber
- Precision Rating: ISO Class 0
- Performance: Standard Duty
- Locking Device: Set Screw
- Lubrication: Relubricatable
- Basic Outer Ring: 210
- Static Load Rating: 5200 lbf, 23200 N, 23.20 kN
- Dynamic Load Rating: 7850 lbf, 35000 N, 35.00 kN
- Enclosure: Double Sealed
- Weight: 1.720 lb, 0.780 kg
- Operating Temperature Range: -40 to 250 ºF, -40 to 120 ºC
- d: 2.0000 in, 50.800 mm
- D: 3.5433 in, 90.000 mm
- C: 0.9843 in, 25.000 mm
- B: 2.0315 in, 51.600 mm
- r: 0.0591 in, 1.500 mm
- ds: 5/16-24 UNF
- G: 0.3543 in, 9.000 mm
- d4: 2.4567 in, 62.400 mm
- S1: 1.2835 in, 32.600 mm
- S: 0.7480 in, 19.000 mm
- F: 0.2323 in, 5.900 mm
- Series: UC2
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
