NTN UC213 INSERT BEARING
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: UC213
IMS Product Code: 1783670
Packaging: Sold Individually
Description:
NTN UC213 Insert Bearing
Insert Bearing
Specifications
- Type: Insert Bearing
- Bore Type: Round
- Bearing Type: Ball Bearing
- Material: Through Hardened Steel
- Limiting Speed - Grease: 2400 RPM
- Seal Type: Contact
- Seal Material: Nitrile Rubber
- Precision Rating: ISO Class 0
- Performance: Standard Duty
- Locking Device: Set Screw
- Lubrication: Non-Relubricatable
- Basic Outer Ring: 213
- Static Load Rating: 9000 lbf, 40000 N, 40.00 kN
- Dynamic Load Rating: 12900 lbf, 57500 N, 57.50 kN
- Enclosure: Double Sealed
- Weight: 4.189 lb, 1.900 kg
- Operating Temperature Range: -40 to 250 F, -40 to 120 C
- d: 2.5591 in, 65.000 mm
- D: 4.7244 in, 120.000 mm
- C: 1.2598 in, 32.000 mm
- B: 2.5630 in, 65.100 mm
- r: 0.0787 in, 2.000 mm
- ds: M10x1.25
- G: 0.3937 in, 10.000 mm
- d4: 3.2480 in, 82.500 mm
- S1: 1.5630 in, 39.700 mm
- S: 1.0000 in, 25.400 mm
- Dimensions: 65x120x32mm
