NTN UCL208-30 STRETCHER UNIT
Quick Overview
Manufactured By: NTN
Manufacturer Part Number: UCL208-30
IMS Product Code: 2150250
Packaging: Sold Individually
Description:
NTN UCL208-30 Stretcher Unit
Stretcher Unit, Set Screw, UCL Type
Specifications
- Type: Stretcher Unit
- Bearing Type: Ball Bearing
- Locking Device: Set Screw
- Bearing Number: UC208
- Frame Number: L208-30
- Performance: Light Duty
- Dynamic Load Rating: 6542 lbf, 29100 N, 29.10 kN
- Static Load Rating: 4002 lbf, 17800 N, 17.80 kN
- Max. Recommended Load: 1010 lbf, 4500 N
- Rotational Speed [Max]: 3700 RPM
- Weight: 21.389 lb, 9.700 kg
- Operating Temperature Range: -40 to 250 degrees F, -40 to 120 degrees C
- Lubrication: Non-Relubricatable
- d: 1.5750 in, 40.000 mm
- H: 3.8189 in, 97.0 mm
- H1: 7.3228 in, 186.0 mm
- L: 26.3780 in, 670.0 mm
- L1: 22.0472 in, 560.0 mm
- J: 24.0157 in, 610.0 mm
- J1: 6.1024 in, 155.0 mm
- J2: 11.8110 in, 300.0 mm
- B: 1.9370 in, 49.200 mm
- S: 0.7480 in, 19.000 mm
- Frame Type: Stretcher Unit
- Country of Origin: JP
- Base Width: 60 mm
- Travel: 300 mm
- Bolt Hole Spacing: 24.0157 in, 610.0 mm
- Frame Overall Length: 670 mm
- Frame Overall Height: 186 mm
- Duty Type: Light Duty
- Frame Base Width: 60 mm
- Frame Size: L208-30
- Overall Height: 186 mm
- Overall Length: 670 mm
- Overall Width: 60 mm
- Bolt Size: M12
- Max Rpm: 3700 rpm
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 16 hours and 16 minutes.
