NUMATICS 081SA431M000061 4/2 SOLENOID VALVE
Quick Overview
Manufactured By: NUMATICS
Manufacturer Part Number: 081SA431M000061
IMS Product Code: 2002437
Packaging: Sold Individually
Description:
Numatics 081SA431M000061 4/2 Solenoid Valve
Pneumatic solenoid valve with 4-way 2-position spring return function, 24 VDC voltage, and 1/8" NPT port size.
Specifications
- CV: 0.8 TO 1.0
- Port Sizes: 1/8, 1/4 NPTF & G
- Flow Capacity: 37 TO 46 SCFM @ 80 PSIG / 790 TO 985 NI/M @ 6 BAR
- Operating Pressure Range: 28" HG. VACUUM TO 150 PSIG / VACUUM TO 10 BAR
- Pilot Pressure Range: 20 TO 115 PSIG / 1.5 TO 8 BAR
- Temperature Range (Ambient): -10?F TO +115?F / -23?C TO +46?C
- Port Size: 1/8"
- Port Type: NPT
- Control Function: SINGLE DIRECT SOLENOID
- Valve Function: 4 WAY 2 POSITION - (5/2) SPRING RETURN
- Voltage: 24 VDC
- Port Location: SIDE PORTS
- Exhaust Option: COMMON EXHAUST
- Wiring: PLUG-IN
- Speed Control: NO
- Special Option: NONE
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 10 minutes.
