NUMATICS 122RD100J000000 DUAL PRESSURE REGULATOR
Quick Overview
Manufactured By: NUMATICS
Manufacturer Part Number: 122RD100J000000
IMS Product Code: 1756802
Packaging: Sold Individually
Description:
Numatics 122RD100J000000 Dual Pressure Regulator
Dual pressure regulator with plug-in wiring, 1/4" port size, and 10-130 PSIG pressure range.
Specifications
- Regulator Type: Dual Pressure to Ports 3 & 5
- Pressure Range: 10-130 PSIG
- Port Size: 1/4"
- Wiring: Plug-in
- Flow Capacity: 56 SCFM @ 80 PSIG
- Operating Pressure Range: 28”Hg Vacuum to 150 PSIG
- Pilot Pressure Range: 26 to 120 PSIG
- Temperature Range: -10°F to +115°F
- Power (watts): 2.5/4.2
- Holding Current (amps): 0.1/0.05
- Response Time: 0.01/0.02 seconds
- CV: 1.2
- Weight: 0.56 LBS
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships today if ordered in the next 9 hours and 31 minutes.
Used (Special):
Connected to model# 006-158D
Availability: 1 In Stock
Ships today if ordered in the next 9 hours and 31 minutes.
