PANDUIT UTP28SP8IN CAT 6 UTP PATCH CORD
Quick Overview
Manufactured By: PANDUIT
Manufacturer Part Number: UTP28SP8IN
IMS Product Code: 1780856
Packaging: Sold Individually
Description:
Panduit UTP28SP8IN Cat 6 UTP Patch Cord
Cat 6 UTP copper patch cord with 28 AWG stranded conductors, 8in length, Off White CM/LSZH jacket, RJ45 connectors.
Specifications
- Application: 1000BASE-T (Gigabit Ethernet), 100BASE-T (Fast Ethernet), 155 Mb/s ATM, 622 Mb/s ATM, 1.2 Gb/s ATM, Digital video, Voice/data systems, Voice over Internet Protocol (VoIP)
- Boot Color: Clear
- Cable Construction: U/UTP
- Cable Length: 203 mm
- Color: Off White
- Conductor Gauge (AWG): 28
- Conductor Type: Stranded
- Connector 1 Type: Modular Plug
- Connector 2 Type: Modular Plug
- Connector Type: RJ45 to RJ45
- Contact Plating: Tin
- Diameter: 3.8 mm
- Environmental Classification: CM/LSZH
- Flammability Rating: Dual Rated (CM/LSZH)
- Jacket Material: LSZH Material
- Lengths: 0.6 FT. | 0.18 M
- Max Operating Temperature: 75 degrees C
- Maximum Operating Temperature (F): 167
- Maximum Storage Temperature (F): 158
- Min Operating Temperature: -10 degrees C
- Minimum Operating Temperature (F): 14
- Minimum Storage Temperature (F): -40
- Nominal Cable Outside Diameter (In.): 0.15
- Number of Conductors: 8
- Overall Length (ft.): 0.66
- Patch Cord Type: Unshielded
- Performance Level: Category 6A
- Plug Housing Material: Polycarbonate
- Plug Type: 8 Position
- PoE Compatibility: PoE/PoE+/PoE++
- Product Type: Patch Cord
- RapidID Enabled: Yes
- Shielded: U/UTP - UNSHIELDED TWISTED PAIR
- Shielding: No
- Standards Met: Exceeds all ANSI/TIA-568.2-D Category 6 and ISO 11801 Class E electrical performance requirements for frequencies up to 250 MHz; Meets ANSI/TIA-1096-A; Meets IEC 60603-7; Supports IEEE 802.3af/802.3at (48 cables in a bundle) and 802.3bt type 3 and type 4 (24 cables in a bundle) PoE applications; cULus Listed; UL 1863 and CAN/CSA-C22.2 (UL File E129886); RoHS Compliant
- Type: PATCH CORDS
- UNSPSC Code: 43223303
- Wiring Scheme: T568B
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
