PHOENIX CONTACT 2901536 I/O EXTENSION MODULE
Quick Overview
Manufactured By: PHOENIX CONTACT
Manufacturer Part Number: 2901536
IMS Product Code: 2124486
Packaging: Sold Individually
Description:
Phoenix Contact 2901536 I/O Extension Module
I/O extension module with 4 digital relay outputs (5 A, 250 V AC/DC)
Specifications
- Product type: Extension module
- Number of outputs: 4
- Output name: Relay output
- Contact switching type: Changeover contact
- Contact material: AgSnO2
- Maximum switching voltage: 250 V AC/DC
- Max. switching current: 5 A (250 V AC)
- Supply voltage range: 19.2 V DC ... 30.5 V DC
- Connection method: Screw connection
- Width: 17.5 mm
- Height: 113 mm
- Depth: 114.5 mm
- Material (Housing): PA 6.6-FR
- Degree of protection: IP20
- Ambient temperature (operation): -40 °C ... 70 °C
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 65 In Stock
Ships today if ordered in the next 1 hours and 42 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 2 In Stock
Ships today if ordered in the next 1 hours and 42 minutes.
