PISCO CVF01-01B CHECK VALVE
Quick Overview
Manufactured By: PISCO
Manufacturer Part Number: CVF01-01B
IMS Product Code: 1916419
Packaging: Sold Individually
Description:
Pisco CVF01-01B Check Valve
Check Valve is a versatile component that allows air flow in one direction while preventing flow in the opposite direction, ensuring consistent output pressure.
Specifications
- Body Material: Brass
- Input Side, Port Type P: Female Thread
- Output Side Port Type A: Male thread
- Effective Sectional Area: 6 mm2
- Types of connection port: Rc
- Nominal Mounting Screw: 1/8
- Weight pc(lbs): 0.049
- R: R1/8
- Rc: Rc1/8
- Series: CVF
- Fluid Medium: Air
- Max. Operating Pressure: 0.9 Mpa
- Max. Vacuum: -100 kPa
- Min. Opening Pressure: 0.01 Mpa or less
- Min. Opening Differential Pressure: 0.02 Mpa
- Operating Temperature Range: 0-60 deg. C (No Freezing)
- Body: metal
- Thread Size: Rc1/8
- Tube Size: 1/8"
