SCHNEIDER ELECTRIC 8536SCG1V02 NEMA SIZE 1 MOTOR STARTER
Quick Overview
Manufactured By: SCHNEIDER ELECTRIC
Manufacturer Part Number: 8536SCG1V02
IMS Product Code: 2173888
Packaging: Sold Individually
Description:
Schneider Electric 8536SCG1V02 NEMA Size 1 Motor Starter
NEMA Size 1 non-reversing motor starter with a 27A rating, 2 poles, and 120V AC coil voltage. Used for full voltage starting and stopping of AC squirrel cage motors.
Specifications
- NEMA Starter Size: 1
- Rated Current: 27A
- No. of Poles: 2
- Phase: Single-Phase
- Coil Voltage: 120V AC
- HP Rating: 3 HP at 230V AC, 2 HP at 115V AC
- SCCR: 5 kA
- NEMA Rating: 1
- Enclosure Type: NEMA 1 painted sheet steel
- Height: 10.00 inches (254 mm)
- Width: 6.00 inches (152 mm)
- Depth: 5.56 inches (141 mm)
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
