SICK YF2A15-100UB5XLEAX M12 SENSOR CABLE
Quick Overview
Manufactured By: SICK
Manufacturer Part Number: YF2A15-100UB5XLEAX
IMS Product Code: 2044148
Packaging: Sold Individually
Description:
Sick YF2A15-100UB5XLEAX M12 Sensor Cable
M12 female connector, 5-pin, straight, A-coded with flying leads. 10m PUR cable, halogen-free, unshielded. Rated for 125V AC/DC, 4A. IP65/IP66K/IP67 rated.
Specifications
- Connection Type Head A: Female connector, M12, 5-pin, straight, A-coded
- Connection Type Head B: Flying leads
- Cable Length: 10 m
- Cable Type: 5-wire, PUR, halogen-free, unshielded
- Signal Type: Sensor/actuator cable
- Rated Current: 4A
- Rated Impulse Voltage (Uimp): 1.5 kV
- Degree of Protection: IP65 / IP66K / IP67
- Material: PUR jacket / TPU connector / Nickel-plated die-cast Zinc locking nut / FKM seal
- Ambient Air Temperature for Operation: -25°C...+80°C
- Cross-section: 0.34mm2
- Torque: 0.6N.m (tightening)
- Color: Black jacket / Black connector
