SIMPSON H335146020 DIGITAL PANEL METER
Quick Overview
Manufactured By: SIMPSON ELECTRIC COMPANY, INC.
Manufacturer Part Number: H335146020
IMS Product Code: 2132233
Packaging: Sold Individually
Description:
Simpson H335146020 Digital Panel Meter
3.5 digit digital panel meter with 7 segment red LED display, 120V supply voltage, and optional relay outputs.
Specifications
- Display Type: 7 segment red LED
- Display Size: 4-1/2 or 3-1/2
- Input Type: 5AAC
- Supply Voltage: 120V
- Number of Relays: One, two or four
- Relay Rating: 5-amp
- Brightness Levels: Five
- Case Depth: 3.24" behind panel
- Excitation Output: 12 or 24 DCV optional
- Excitation Output Current: maximum 30mA @ 12V and 20mA @ 24V
- Analog Retransmission: 4-20mA or 0-10 DCV optional
- Front Panel Rating: NEMA 4X
- Special Features: Peak/Valley and password lockout
- Installation: Screw terminals
