SKF 6207 2ZJEM DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: SKF
Manufacturer Part Number: 6207 2ZJEM
IMS Product Code: 1834222
Packaging: Sold Individually
Description:
SKF 6207 2ZJEM Deep Groove Ball Bearing
Deep groove ball bearing with double shielded design, 35 mm bore diameter, 72 mm outside diameter, and 17 mm width.
Specifications
- Bore Diameter: 35 mm
- Outside Diameter: 72 mm
- Width: 17 mm
- Dynamic Load Rating: 25.7 kN
- Static Load Rating: 15.3 kN
- Limiting Speed: 13000 rpm
- Bore Type: Straight
- Contact Angle: Not Applicable
- Closure Type: Double Shielded
- Snap Ring Included: Without Snap Ring
- Internal Clearance: C3
- Cage Type: Sheet metal
- Precision Rating: ABEC 3
- Finish Coating: Uncoated
- Bearing Material: Bearing steel
- Cage Material: Bearing steel
- Inner Ring Width: 17 mm
- Element Material: Bearing steel
- Fillet Radius: 1 mm
- Max Rpm: 10000 rpm
- Series: 62
- Radial Dynamic Load Capacity: 6070 lbf
- Radial Static Load Capacity: 3440 lbf
- Weight: 0.67 lbs
- Seal Material: Tinplate
